Y-Pattern Forged Check Valve

Y-Pattern Forged Check Valve
FAVA Valves manufactures Y-Pattern Forged Check Valves in three kinds bonnet design—Bolted Bonnet,Welded Bonnet and Pressure Sealed Bonnet.

Construction Features:
Forged Steel,Piston,Ball or Swing type
Integral Body Seat for Piston and Ball Check valves
Separated Seat Ring design for swing check valves
Spiral Wound Gasket or Oval Ring Joint gasket
Reduced Bore or Full Port,
T-Pattern or Y-Pattern,
Socket Welded,Threaded,Butt Welded,Flanged End.



Y-Pattern Forged Check Valves
Application standards

  1. Design and manufacture conform to ASME B 16.34 , MSS SP-118;
  2. Connection ends conform to
    1. Socket welded ends conform to ANSI B16.11 , JB/T1751
    2. Screw ends conform to ANSI B1.20.1 , JB/T7306
    3. Butt-welded ends conform to ANSI B 16.25 , JB/T12224
    4. Flanged ends conform to ANSI B16.5 , JB79
  3. Test and inspection conform to: API 598 , GB/T13927 , JB/T9092
  4. Structure features:
    A threaded and pressure seal bonnet , Y type and T type.
  5. Materials conform to ANSI/ASTM
  6. Main materials:
    A105 , LF2 , F5 , F11 , F22 , 304(L) , 316(L) , F347 , F321 , F51 , Monel , 20 Alloy

We could provide Y pattern forged check valves with different materials. If you do not find the material you need, please contact us.
Part name A 105/F6a A105/F6aHFS LF2/304 F11/F6aHF F304(L)
304(L)
F316(L)
316(L)
F51
F51
Body A105 A105 LF2 F11 F304(L) F316(L) F51
Disc 410 410HF 304 410HF 304(L) 316(L) F51
Gasket 304+
Flexible graphite
304+
Flexible graphite
304+
Flexible graphite
304+
Flexible graphite
304+
Flexible graphite
316+
Flexible graphite
316+
Flexible graphite
Bonnet A105 A105 LF2 F11 F304(L) F316(L) F51
Bolt B7 B7 L7 B16 B8(M) B8(M) B8M
Nameplate AL AL AL AL AL AL AL
Steel ball 430 430 304 STL 316(L) 316(L) STL
